SPECIFICATIONS

Hign-concerned Chemical: None

Interchange Part Number: 2701

Item Height: Dual Plane Intake Manifold for Small Block Chevy 305 327 350 V8

Item Length: 55cm

Item Weight: For Small Block Chevy SBC 262-400 Aluminum Dual Plane

Item Width: 28cm

Manufacturer Part Number: 2701

Material: Aluminum

OEM NO.: 2701

Origin: Mainland China

Other Part Number: 2701

Placement on Vehicle: for Chevrolet Small Block 305 350 ci 262-400

Special Features: 2701

Description:

#2701 Performer EPS intake manifold is designed for 1986 and earlier 262-400
cubic-inch Chevys. Dual-plane, low-rise design with a 180-degree firing
order greatly improves torque over a wide rpm range for excellent
throttle response. With that the Performer EPS intake manifold has a
runner design that's "tuned" for peak torque at 3500 rpm on a 350-inch
engine making it ideal for power from off-idle to 5500 rpm. Dyno tests
showed gains of 5 hp and 9 ft-lbs. of torque over the Performer manifold
#2101 on a 350 Chevy. From 3000 to 4500 rpm, the power increases
averaged 5+ ft-lbs. of torque for more performance where you need it
most.

Specifications:

Material Type: Aluminum

Finish: Natural

Carburetor Quantity: 1

Intake Section Included: Complete

RPM Range: Idle-5,500

EGR: No

Port Height: 1.85

Fuel System Type: Carbureted

Bolt Hole Pattern: 5.160" x 5.625"

Sold in Quantity: Each

Intake Manifold Type: Dual Plane

Carburetor Flange Type: 4-Barrel Square Bore

MFG. Part #: 2701

Gaskets Included: No

Overall Height: 4.25

Port Width: 1.15

Mounted Height: 4.25

Notes: 500-650 CFM carb. is recommended

OE Number:

2701

Will Fit Following Models:

For 1955-1986 Small Block Chevy
